Impact Sprinkler w/ 5 lb. Weighted Sled Base

Impact Sprinkler w/ 5 lb. Weighted Sled Base


Regular price Price: $129.00
Regular price Sale price $129.00 USD
Sale Sold out

Free Ground Shipping within the continental US! The Heavy Duty Brass Impact Sprinkler with 5 lb. weighted sled base is a great choice for general use on large areas where you need the sprinkler to operate continuously in a full circle. This is a heavy duty brass sprinkler that is not available in local stores and will give you years of worry free operation.  It comes with two nozzle sizes, 4mm and 5mm to accommodate a flow range of 3 to 10 gallons per minute and up to 90+ feet in diameter!  Applications include large yard areas, vegetable or flower gardens, orchard or shrub areas, and much more!  Again, this is not a Heavy Duty Brass Impact Sprinkler that you will find in local stores and is a great value for the price! The Heavy Duty Residential “Impact” Sled featuring the New R3S Max Drive sprinkler from our Green Pro Line Series of commercial grade sprinkler heads.

The sled base is laser cut from 3/16” steel plate and formed into the most durable sled bases on the market!  Weighing in at a robust 5 pounds, this new sled base will stand the test of time and allows for strength and stability while the Heavy Duty Brass Impact Sprinkler is operating.  In addition to the already durable construction, the sled is available with a brilliant green powder coat baked-on finish.Each component in this assembly has been selected for quality including the heavy steel water path components and heavy duty brass garden hose connections!

The all new R3S Max Drive impact sprinkler also comes with a full set of nozzles allowing flow ranges from 3 to 8 gallons per minute.  This sprinkler also features an adjustable jet stream breaker for changing stream pattern and may be operated in full circle mode or part circle mode by simply adjusting the part circle tabs at the base of the sprinkler.  This quality sprinkler is constructed from a cast aluminum alloy body with brass lower turning union.  The Max Drive action of this sprinkler uses the perfect combination of drive arm spring tension and engineered mechanical designs to display a beautiful stream pattern in forward and fast reverse mode that results in the absolute best wetted water pattern all throughout the diameter of the circle.  The Max Drive stays consistent at low and high pressures.

The Impact sled also features a Flow-Through Base design allowing multiple sled bases to be connected in series!

Quality made in the USA!

View full details


  • Inlet Size:Garden hose connection
  • Connection Hose Needed:3/4" Professional Contractor Grade Garden Hose Recommended
  • Flow Rates:3 to 8 gallons per minute
  • Available Nozzles:4 mm, 5 mm, 6 mm, Included
  • Pressure Range:30 - 60 PSI Recommended
  • Trajectory Angle:30°
Impact Sprinkler w/ 5 lb. Weighted Sled Base

Features and Benefits

  • Heavy 3/16" Formed Steel Base
  • Powder Coated or Galvanized
  • Heavy Duty Steel Fluid Path
  • 3 to 8 gpm flow range
  • Green Pro Line Series - R3S Max Drive sprinkler with 30 degree trajectory
  • 5 lb. Weighted Base for Stability w/ Flow-Thru Design for Connecting Multiple Bases in Series
  • Option of Powder Coated or Galvanized sled base

Primary Applications

  • Medium to Large area Lawn or Garden Watering
  • Shrub or Landscape Watering
  • Indoor & Outdoor Nursery Watering
  • Dust Suppression
